In a groundbreaking development poised to reshape the landscape of solar energy technology, researchers at EPFL’s Photovoltaics and Thin-Film Electronics Laboratory (PV-Lab) in collaboration with CSEM have engineered an innovative triple-junction solar cell that seamlessly merges extraordinary voltage, elevated efficiency, and scalable manufacture. This new device leverages a silicon bottom cell layered with middle and top cells composed of perovskite thin films—a class of semiconductors garnering immense interest for their optoelectronic properties. The cell’s independently certified efficiency of 30.02% sets a new benchmark, surpassing the previous pinnacle of 27.1%, and marking a pivotal stride in photovoltaic research.
The exceptional performance realized by this triple-junction architecture is particularly notable considering its scalability and cost-effectiveness compared to traditional high-efficiency cells. Kerem Artuk, the lead author of the study and an EPFL alumnus now at CSEM, emphasizes that this design mirrors the performance of the most advanced space-grade III-V multi-junction solar cells, which typically achieve efficiencies near 37% yet demand materials and manufacturing processes that are prohibitively expensive for terrestrial applications. By contrast, this perovskite-silicon hybrid approach offers a promising path toward high-efficiency photovoltaics at a fraction of the cost.
Achieving this milestone was anything but straightforward. Conventional triple-junction cells are often constrained by low voltage output in the upper cell and insufficient current in the middle cell, limitations that historically capped their overall performance. To address these challenges, the EPFL-CSEM team implemented three innovative modifications to the cell’s material and optical structure. First, they introduced a specialized molecule during perovskite formation, effectively guiding crystal growth and eradicating defects that typically hinder voltage enhancement. This led to a remarkable boost in the top cell’s voltage, reaching 1.4 volts under sunlight—a significant leap forward in perovskite cell technology.
The second breakthrough involved a novel three-step fabrication process tailored for the middle perovskite cell, meticulously engineered to augment light harvesting in the near-infrared domain, a spectral region previously underserved in multi-junction devices. This refinement dramatically enhances the cell’s current generation capabilities, directly impacting the overall power conversion efficiency. Complementing this, the third innovation strategically positioned nanoparticles between the bottom silicon layer and the middle perovskite cell. These nanoparticles act as reflective agents, redirecting otherwise lost photons back into the middle layer, thereby elevating its absorption efficiency and current output.
Beyond the technical marvels, this advancement signals a paradigm shift toward making high-efficiency solar technology accessible and practical for everyday use. Both perovskite materials and silicon substrates benefit from mature, cost-effective manufacturing routes, especially when contrasted with the specialized, costly III-V semiconductor processes which dominate in aerospace applications. With this scalable, low-cost fabrication blueprint, the door opens for multi-junction photovoltaics to transition from satellite-exclusive solutions to mainstream commercial and residential energy systems.
The project, spearheaded by Christian Wolff and his team at EPFL, is not merely a demonstration of power conversion efficiency but a holistic illustration of integrating fundamental science with cutting-edge engineering. Their ongoing roadmap includes pursuing scale-up strategies in partnership with CSEM, alongside rigorous durability assessments crucial for real-world deployment. The researchers aim to ensure these high-performing cells can maintain their stability and performance over extended operational lifetimes, addressing one of the most significant barriers facing perovskite technologies.
This breakthrough also rekindles enthusiasm for multi-junction solar cells’ potential, which theoretically can exceed 40% efficiency by optimizing material combinations and photon management strategies. The silicon-perovskite system, bolstered by tailored crystallization techniques and photonic enhancements, brings this optimistic projection within tangible reach. Notably, this achievement represents a five-fold improvement over the group’s 2018 prototype, which initially demonstrated a modest 13% efficiency, underscoring rapid advancements in materials science and device engineering over a relatively short period.
Fundamentally, the triple-junction design capitalizes on the complementary absorption spectra of each semiconductor layer. The top perovskite tuned for high voltage, the middle perovskite maximizing near-infrared capture, and the silicon bottom cell harvesting the remaining longer-wavelength light—together, this stratified architecture efficiently converts a broader segment of the solar spectrum. The strategic deployment of nanoparticles further refines the internal light environment, exemplifying how photon and carrier management synergistically elevate device performance.
This research heralds an era where perovskite-based multi-junction solar cells do not merely rival but surpass existing terrestrial photovoltaics in both performance and cost-efficiency. Moreover, the potential to fine-tune these cells for specialized applications—including space missions where weight, efficiency, and cost are critically balanced—positions this innovation at the confluence of academic inquiry and industrial transformation.
Refining the fabrication process to be scalable and integrating robustness into these cells will be the next critical milestones. The collaboration between EPFL and CSEM is actively exploring these avenues, envisioning seamless incorporation of the technology into commercial products. The team’s multidisciplinary approach—merging materials chemistry, optical physics, and precision engineering—embodies the Swiss tradition of excellence and innovation in renewable energy technologies.
In conclusion, this triple-junction solar cell breakthrough is more than a record in energy conversion efficiency—it symbolizes a transformative advance in photovoltaic science. By harnessing perovskite materials’ versatility and silicon’s reliability, combined with innovative optical engineering, this research sets a new paradigm for cost-effective, high-performance solar energy solutions that are scalable for widespread adoption. As the push for sustainable energy intensifies globally, innovations such as these catalyze the transition toward cleaner, more affordable power sources for the planet’s future.
Subject of Research: Advancement in triple-junction perovskite-silicon solar cells achieving record efficiency through novel material and photonic engineering.
Article Title: Triple-junction solar cells with improved carrier and photon management
News Publication Date: 17-Mar-2026
Web References:
Image Credits: © Kerem Artuk
Keywords
Triple-junction solar cell, perovskite photovoltaics, silicon solar cell, multi-junction efficiency, photon management, carrier management, scalable manufacturing, high-efficiency solar energy, renewable energy technology, photovoltaic innovation
