Cosmic-Ray Muons Reveal Gigavolt Electric Fields Hidden Inside Thunderstorms

An instrument built half a world away from any meteorological laboratory, designed to catch particles arriving from deep space, has become one of the most powerful tools available for probing the electricity of thunderstorms. The GRAPES-3 muon telescope, located in Ooty in southern India, was constructed to study cosmic rays, the relentless rain of high-energy particles that strikes Earth’s atmosphere from all directions. Yet in recent years its researchers discovered that the same detector could sense something far closer to home: the enormous electric fields that build up inside thunderclouds. A new study by the same team, published in the Journal of Cosmology and Astroparticle Physics, has now resolved a puzzling asymmetry in their thunderstorm observations, and in doing so has strengthened the case for using cosmic-ray secondaries as a natural, continuously available probe of atmospheric electricity.

The story begins with the physics of cosmic rays themselves. Most primary cosmic rays are protons, electrically charged particles whose trajectories are bent by Earth’s magnetic field before they ever reach the atmosphere. When they arrive, they collide with atomic nuclei in the air and generate cascades of secondary particles. Among these secondaries are muons, short-lived charged particles produced at high energies that travel at nearly the speed of light and penetrate deep into the atmosphere. As Sunil Gupta of the Tata Institute of Fundamental Research (TIFR) in Mumbai, one of the authors of the study, explains, the cosmic rays detected at ground level consist predominantly of these highly penetrating muons. The GRAPES-3 facility includes a 560-square-metre muon telescope that records around four billion muons every day, providing an extraordinarily dense stream of data.

Crucially, those muons are not evenly balanced in electric charge. Because the primary cosmic rays are mostly positively charged, positive muons are more abundant in the atmosphere than negative ones. Physicists quantify this imbalance with the muon charge ratio, the number of positive muons divided by the number of negative ones, which normally exceeds one. That small excess is what allows GRAPES-3 to do something it was never originally designed to do. Inside a thundercloud, electric charges become separated, producing intense electric fields and large potential differences. When muons cross these regions, the field acts on positive and negative particles in opposite ways, generally slowing positive muons while accelerating negative ones. If the two charges were present in equal numbers, these effects would cancel almost perfectly, leaving no detectable change in the total muon flux.

Hari Haran Balakrishnan of TIFR, first author of the new study, puts the point starkly: if nature provided equal numbers of positive and negative muons throughout the telescope’s field of view, the thunderstorm phenomenon simply could not be observed with the current setup. Because positive muons dominate, however, each thunderstorm leaves a small but measurable imprint on the total muon count, and from that imprint researchers can infer the electrical potential inside the cloud. Gupta describes muons as an ideal gift for these kinds of studies, likening them to an electric current flowing through the atmosphere. In an earlier analysis, the team reported a striking result: a potential of 1.3 gigavolts measured in a single thunderstorm, a figure that dwarfs anything obtained by conventional means.

The idea that thunderstorms might generate potentials on that scale is not new. As early as the 1920s, the physicist Charles Thomson Rees Wilson, who would later win the 1927 Nobel Prize in Physics, suggested that thunderclouds could reach such enormous voltages. Direct measurements, however, had previously topped out at only around 130 million volts, more than an order of magnitude lower. The difficulty is practical as much as conceptual: sampling the interior of a large, rapidly evolving storm generally requires instruments carried by aircraft or weather balloons into or near active weather, a hazardous and spatially limited approach. Muons invert the problem entirely. They pass through the atmosphere continuously, they can be monitored from the safety of the ground, and they sample the whole volume of the cloud along their paths.

But the earlier GRAPES-3 observations carried an unexpected puzzle alongside their headline result. Between April 2011 and December 2020, the telescope detected 487 thunderstorm events, and their distribution across the sky was strikingly lopsided. Fully 81.5 percent of the events appeared in the eastern part of the instrument’s field of view, while only 13.7 percent appeared in the west, a difference of almost six to one. The obvious suspicion was local weather: perhaps storms in this part of India genuinely favour the east. An independent array of instruments that monitors the atmospheric electric field said otherwise. Actual thunderstorms, measured directly, showed no comparable preference for the eastern sky, which meant the asymmetry had to originate in the detector rather than in the atmosphere.

The answer lies in an effect that atmospheric and cosmic-ray physicists have known about for nearly a century: the east-west effect. Because cosmic-ray protons are charged, Earth’s magnetic field filters their arrival directions. Lower-energy positive particles arriving from the east are screened out more strongly than those arriving from the west, so the mix of cosmic rays, and therefore of secondary muons, depends on direction. This directional threshold, known as the geomagnetic cutoff, varies significantly across GRAPES-3’s field of view. The consequence is that the muon charge ratio, the very quantity that makes thunderstorm sensing possible in the first place, is itself direction-dependent, and the telescope is therefore more sensitive to thunderstorms in some parts of the sky than in others.

To test whether this could account for the observed lopsidedness, the researchers turned to computer simulations that model the production and propagation of muons through the atmosphere. The simulations showed that the balance between positive and negative muons changes markedly with direction: the muon charge ratio is about 1.37 in the east but only 1.14 in the west. That difference, they found, is more than enough to explain the event counts. As Gupta emphasizes, it is not that the voltage is different; thunderstorms to the east are not necessarily more electrically powerful than those to the west. Rather, the larger imbalance between positive and negative muons arriving from that direction makes the telescope more responsive to their electrical effects. The simulations confirmed the mechanism in both directions: when the direction-dependent charge ratio was included, a strong east-west asymmetry emerged, closely resembling the observations, and when the same ratio was imposed in both directions the asymmetry disappeared entirely.

The resolution of the puzzle matters well beyond bookkeeping for one detector. Understanding this directional sensitivity is essential if GRAPES-3 is to serve as a reliable, calibrated probe of thunderstorm electricity, because any inferred potential must account for how efficiently the instrument responds along each line of sight. With that correction in hand, the technique offers something no balloon campaign can match: continuous, ground-based monitoring of the largest electric fields in nature, drawn from a particle flux that arrives whether or not anyone is watching. The broader significance is considerable, since thunderstorm electrification is linked to lightning initiation, to terrestrial gamma-ray flashes, and to the still-uncertain role of storms in the global atmospheric electrical circuit. What began as an instrument for studying particles from the cosmos has ended up illuminating one of the most familiar and, remarkably, still one of the most mysterious phenomena on our own planet. The same muons that carry messages about distant astrophysical sources now carry, quite literally, the voltage of the storm overhead.
