In a groundbreaking advancement at the crossroads of nanophotonics and display technology, researchers have unveiled a revolutionary approach that promises to reshape the future of holographic image projection. By integrating organic light-emitting diodes (OLEDs) directly with metasurfaces—ultrathin, engineered materials capable of manipulating light with subwavelength precision—this new platform offers unprecedented control over holographic displays, pushing the boundaries of visual experience and optical engineering.
Holography as a display technology has long tantalized scientists and engineers with the promise of three-dimensional, glasses-free imagery that can render scenes with lifelike depth and parallax. However, conventional holographic projectors require bulky optical setups and external coherent light sources, limiting their practicality and integration. The innovative method developed by Gong and colleagues, recently published in Light: Science & Applications, seamlessly fuses OLEDs and metasurfaces into a compact, monolithic structure. This marriage allows the OLED itself to act as both the illumination source and the modulator for holographic wavefront shaping, eradicating the need for external lasers or spatial light modulators.
At the heart of this technology lies the concept of metasurfaces: planar arrays of nanostructures engineered to shape electromagnetic waves in designated manners, often by controlling phase, amplitude, or polarization with extraordinary spatial resolution. While metasurfaces have previously been illuminated using external lasers, the integration with OLEDs introduces an intrinsic light source patterned at the microscale. This innovation offers a stable, electrically driven, and wavelength-scalable platform capable of holographic image projection with high fidelity—a significant leap from traditional bulky systems.
The OLED layer provides incoherent, broadband emission, a characteristic historically viewed as a challenge for holography, which typically requires coherent light to reconstruct wavefronts. Yet, the team ingeniously designed metasurfaces matching the emission spectrum and spatial coherence properties of the OLED. By tailoring nanostructures that harness and modulate the partially coherent light, they enable the formation of well-defined holographic images without relying on lasers. This breakthrough could democratize holographic displays, making them more energy-efficient, cost-effective, and compatible with flexible substrates.
Fabrication techniques played a pivotal role in achieving the precise nano-architecture required for functional metasurfaces directly on OLEDs. The researchers utilized advanced lithography methods to pattern metallic and dielectric nanostructures atop the OLED surface with nanometer precision. This ensures effective phase modulation while preserving OLED performance and longevity. The successful integration underscores the compatibility of nanofabrication technologies with organic electronic devices, opening avenues for multifunctional photonic platforms.
Experimentally, the research team demonstrated vivid holographic projections that varied from simple geometric shapes to complex images with intricate depth cues. The reconstructed holographic patterns exhibited angular robustness and brightness levels typically unattainable with incoherent illumination. By controlling pixelated metasurface regions synchronized with the OLED emission, the system modulates the wavefront dynamically, hinting at the potential for real-time holographic videos.
A significant advantage of the OLED-metasurface platform is the scalability and versatility. Since OLED fabrication is well-established in commercial display manufacturing, integrating metasurfaces into existing production lines could fast-track development into consumer electronics, augmented reality devices, and wearable holograms. The low power consumption, flexibility, and thin form factor position this technology as a frontrunner for next-generation immersive displays.
The researchers also addressed the challenge of speckle noise, prevalent in holography and resulting from laser coherence and scattering. The incoherent emission of OLEDs inherently reduces speckle artifacts, producing clearer and smoother holographic images. Furthermore, the ability to lithographically engineer metasurfaces to compensate for phase aberrations and color dispersion further enhances image quality, setting a new benchmark in holographic display clarity.
The versatility of this platform paves the way for applications beyond consumer displays. Potential uses include secure optical encryption by encoding holograms into metasurfaces, biomedical imaging employing compact holographic microscopes, and adaptive lighting systems offering tailored illumination patterns. This multifaceted utility exemplifies how merging two emerging technologies—OLEDs and metasurfaces—can spawn transformative optical devices.
Moreover, the research hints at the feasibility of dynamic holography by integrating electrically tunable metasurfaces with OLED backplanes. Employing materials such as phase-change compounds or liquid crystals within the metasurface layer could allow active scanning and updating of holographic images. This dynamic control is essential for real-time holographic video displays, spatial light modulation, and interactive interfaces.
The impact of this development extends into fundamental optics, providing new insights into managing light-matter interactions on ultrathin platforms. By exploiting the partially coherent, broadband emission of OLEDs through carefully designed nanostructures, the work challenges conventional wisdom that holography necessitates coherent laser sources. This paradigm shift could stimulate further investigations into incoherent holography, multimode wavefront control, and hybrid photonic devices.
In scaling these devices for commercial use, challenges remain, notably in optimizing the efficiency of the metasurface modulation to maximize brightness and minimize losses at the nanoscale. The stability and lifetime of OLEDs under the additional processing steps of metasurface integration also warrant attention. Nevertheless, the team’s promising initial demonstrations indicate a clear path forward with ongoing material and fabrication advancements.
Intriguingly, the co-design approach adopted by Gong et al., involving simultaneous optimization of the emission characteristics of OLEDs and the phase and amplitude response of metasurfaces, represents a visionary strategy to engineer holistic photonic systems. This integrated approach contrasts traditional designs, where emitters and modulators are treated as separate entities.
Looking to the future, the researchers envision embedding full-color holographic displays with ultrahigh resolution directly into flexible form factors like fabric wearables, transparent windows, or even curved surfaces on vehicles and architectural elements. Such pervasive holography could redefine human-computer interaction, spatial communication, and artistic expression.
In summary, this pioneering work on OLED illuminated metasurfaces for holographic image projection not only unveils a disruptive technology platform but also reinvents the foundational principles of holography by harnessing incoherent light sources at the nanoscale. The confluence of nanofabrication, organic electronics, and wavefront engineering promises to spur a new era of visually immersive technologies that are more accessible, compact, and versatile than ever before.
Subject of Research: OLED illuminated metasurfaces enabling compact, coherent-light-free holographic image projection.
Article Title: OLED illuminated metasurfaces for holographic image projection.
Article References:
Gong, J., Biabanifard, M., Yoshida, K. et al. OLED illuminated metasurfaces for holographic image projection. Light Sci Appl 14, 294 (2025). https://doi.org/10.1038/s41377-025-01912-z
