Central Cooling and Heating Process Tames the Shadow Effect in Single-Crystal Superalloy Casting

Every jet engine flying today depends on a manufacturing miracle that most people never think about: nickel-base single-crystal superalloy turbine blades, cast as one continuous, defect-free crystal that can survive temperatures hot enough to soften ordinary metals. But producing these crystals is notoriously difficult, and when manufacturers try to cast a cluster of large-caliber components at once, a stubborn physics problem called the shadow effect sabotages the process, causing high rejection rates and enormous waste. Now, a team of researchers in China has demonstrated a central cooling and heating (CCH) process that can effectively suppress the shadow effect, shrink solidification pores, eliminate freckle defects, and even enhance the rupture life of the finished crystals. The work, published in the Journal of Materials Science, could reshape how the aerospace industry casts its most critical components.

To understand why the shadow effect matters, it helps to picture how single-crystal castings are made. Directional solidification technology works by withdrawing a ceramic mold from a hot furnace zone into a cooler region, so that molten alloy solidifies from the bottom upward along a carefully controlled temperature gradient. The goal is for a single crystal orientation to propagate through the entire component. But when a cluster of large-caliber castings is arranged together in the furnace, the components block each other’s view of the cooling surfaces. One casting literally casts a thermal shadow on its neighbor, disrupting the local heat flow and the temperature gradient that the solidification front depends on. The result is one of the primary causes of casting defects in Ni-base single-crystal superalloy castings, including stray grains, freckles, and solidification pores that force manufacturers to scrap otherwise valuable parts.

The research team, led by Donghan Fan, Naicheng Sheng, and Yizhou Zhou of the University of Science and Technology of China and the Institute of Metal Research, Chinese Academy of Sciences, in collaboration with AECC Shenyang Liming Aero-Engine Co., Ltd, investigated a novel central cooling and heating process as a way to fight back against this thermal shadowing. Instead of relying solely on the conventional withdrawal-based cooling from the outside, the CCH process introduces controlled cooling and heating from the center of the casting cluster. This central intervention changes the radiation heat transfer dynamics inside the furnace, so that each component in the cluster receives a more balanced share of the heat exchange. The approach effectively rewrites the thermal geometry of the casting environment, preventing any single casting from being thermally starved by its neighbors.

The experimental results are striking. In CCH-processed castings, the size of the S-pores—solidification pores that form during directional solidification and act as stress concentrators during service—is significantly reduced. Even more dramatically, the freckles are eliminated. Freckles are chains of equiaxed grains that form when segregated interdendritic liquid becomes buoyantly unstable in the mushy zone, the semi-solid region between fully liquid and fully solid material. These freckle chains are catastrophic for single-crystal integrity because they introduce grain boundaries into a component that is supposed to have none. Previous studies have linked freckle formation to geometric features such as edges, curvature, and abrupt cross-section changes in castings, and the mushy zone width plays a decisive role in whether the segregated liquid can destabilize. By narrowing the mushy zone, the CCH process removes the conditions that allow freckles to nucleate in the first place.

Simulation results provide quantitative backing for these experimental observations. The numerical analysis shows that the mushy zone width of CCH-processed castings is shortened by 47.9 percent—a nearly halving of the vulnerable semi-solid region where defects incubate. The temperature field distribution also becomes more uniform across the casting cluster, meaning that the solidification front advances more evenly and the local thermal gradients stay within the safe range for single-crystal growth. A narrower mushy zone reduces the time that segregated liquid spends in the buoyantly unstable state, suppressing the interdendritic fluid flow that drives freckle formation and the shrinkage feeding problems that generate pores.

To clarify exactly how much control the CCH process achieves over the shadow effect, the researchers performed an in-depth deduction of the view factor, a geometric quantity from radiation heat transfer theory that describes how efficiently two surfaces exchange thermal radiation. The view factor analysis demonstrates the radiation heat transfer efficiency inside the furnace and quantifies the level of control over the shadow effect achieved by the central cooling and heating process. In conventional cluster casting, the view factors between neighboring components and the cooling surfaces are distorted by shadowing, so some castings radiate heat inefficiently and solidify under degraded gradients. The CCH process corrects this distortion by inserting central thermal elements that rebalance the radiation exchange, ensuring that the heat extraction from each component stays within the controlled range needed for defect-free directional solidification.

The benefits extend beyond the casting stage into the mechanical performance of the finished crystals. During deformation, a hexagonal dislocation network forms at the deformed gamma/gamma-prime interface in CCH-processed castings. The gamma-prime phase is the ordered intermetallic precipitate that strengthens nickel-base superalloys, and the gamma/gamma-prime interface is where plastic deformation concentrates at high temperatures. Hexagonal dislocation networks at this interface are a well-known signature of effective creep resistance, because they lock the interface and impede dislocation motion through the crystal. The formation of this network enhances the rupture life of the castings, meaning that components produced with the CCH process can withstand high-temperature stress for longer before failing. This is a crucial advantage for turbine blades, which must survive thousands of hours of creep loading at temperatures approaching the melting point of the alloy.

The significance of this work becomes clear when considering the economics of superalloy casting. Single-crystal superalloy components contain expensive alloying elements such as rhenium, and every rejected casting represents a substantial loss of both material and furnace time. The shadow effect is inevitable when directional solidification technology is employed to fabricate a cluster of large-caliber castings, which means that manufacturers have historically accepted high rejection rates as the cost of doing business. A process that suppresses the shadow effect and improves the yield rate of the castings directly translates into lower production costs, less material waste, and more reliable supply chains for the aerospace industry. The CCH process achieves this without requiring changes to the alloy chemistry itself, making it compatible with existing superalloy compositions and casting infrastructure.

The research builds on a growing body of work on defect control in directional solidification. Earlier studies by the same group examined freckle formation during casting single crystal superalloys through the central cooling and heating process, published in the Journal of Alloys and Compd in 2025, and the effect of wall thickness on residual stress and microstructural evolution in multi-blade casting. Other researchers have developed thermal uniformity-based downward directional solidification technologies, non-uniform thickness molds for controlling temperature gradients, and digital twin models for single-crystal turbine blade solidification. The CCH process adds a new dimension to this toolkit by attacking the shadow effect at its geometric root—the distorted radiation exchange within casting clusters—rather than merely compensating for its downstream consequences.

Looking ahead, the combination of experimental validation, quantitative simulation, and view factor analysis demonstrated in this study offers a template for rational process design in superalloy casting. By deducing the radiation heat transfer efficiency from first principles, engineers can now predict how different furnace geometries and central thermal interventions will affect the shadow effect before committing to expensive trial castings. As the demand for single-crystal superalloy components grows with the expansion of commercial aviation and gas turbine power generation, processes like CCH that improve yield rates while enhancing rupture life will become increasingly valuable. The shadow effect has haunted superalloy casting for decades; with central cooling and heating, it may finally be losing its grip.

Subject of Research: Materials Science

Article Title: Suppression of the shadow effect during casting single-crystal superalloys through a central cooling and heating process

Article References: Fan, D., Sheng, N., Chu, Z., Liu, J., Sun, S., Fan, S., Hou, G., Li, J., Zhu, S., & Zhou, Y. (2026). Suppression of the shadow effect during casting single-crystal superalloys through a central cooling and heating process. Journal of Materials Science, 61(43), 33878-33895. https://doi.org/10.1007/s10853-026-13496-z

Image Credits: AI Generated

DOI: 10.1007/s10853-026-13496-z

Keywords: single-crystal superalloys, directional solidification, shadow effect, central cooling and heating, freckles, S-pores, mushy zone, view factor, turbine blades, nickel-base superalloys, Suppression, shadow
