Radioactive Sand Maps Reveal How an Indian Beach Quietly Rebuilds Itself

On a stretch of dark grey sand along India’s west coast, scientists have found that the beach itself carries a hidden signature of its own constant reshaping. A team from the Bhabha Atomic Research Centre mapped natural radioactivity across Jampore beach in Daman, and the resulting radiometric map turned out to be more than a survey of background radiation. It reads like a chart of where the shoreline is quietly gaining ground and where it is being stripped away, offering a way to track coastal sediment movement without ever releasing an artificial tracer into the sea.

The study, published in the journal Discover Oceans, involved measuring gamma radiation at thirty locations spread across an area of roughly two kilometres by six hundred metres, arranged on an imaginary grid with two hundred metres between adjacent points. The researchers used a portable sodium iodide detector sealed inside a PVC pipe to record total gamma counts directly on the beach, logging each position with a handheld GPS receiver. Back in the laboratory, sediment collected from the same thirty sites was dried, sieved and analysed with a high-resolution germanium detector to quantify specific radionuclides. The in-situ counts ranged from 1800 to 6498 counts per minute, and the interpolated map showed that radioactivity was noticeably higher toward the south-west of the beach than the north-east.

What makes the pattern scientifically interesting is that different radionuclides behave in opposite ways depending on the size of the sand grains they inhabit. In the finest fraction studied, grains between 53 and 100 micrometres, the mean activity concentrations of radium-226, radium-228 and potassium-40 were 151.2, 369.4 and 209.7 becquerels per kilogram respectively. In the dominant medium fraction, between 101 and 250 micrometres, the same isotopes averaged just 28.7, 60.6 and 272.6 becquerels per kilogram. In other words, radium concentrates in fine grains while potassium-40 favours coarse ones, a split that reflects two entirely different geochemical stories.

The radium story is one of surface chemistry. Radium-226 and radium-228 are daughter products of the uranium-238 and thorium-232 decay chains, and both isotopes are strongly adsorbed onto particle surfaces. Fine grains carry far more surface area per unit mass than coarse grains, so they adsorb more radium from seawater and pore fluids. Potassium-40 behaves differently: it is an integral constituent of silicate minerals derived from igneous rocks, and its compatibility with silica means it travels locked inside the mineral lattice rather than clinging to grain surfaces. Coarse sediments, being richer in such minerals and less easily washed back out by the tide, end up enriched in potassium-40. The tidal sorting mechanism is simple but effective: waves wash lighter fine grains away and leave heavier particles behind on the beach.

To characterise the sediments chemically, the team used energy-dispersive X-ray fluorescence on the medium grain fraction, which makes up more than seventy percent of the sediment by weight at most locations. The dark grey sand proved mineral-rich, with iron, aluminium, calcium, magnesium, titanium, potassium, vanadium, manganese, zirconium, chromium and lanthanum as the major elements. Mean iron concentration reached about 84,900 parts per million, with aluminium near 54,000 and calcium around 50,000 parts per million. This composition points to substantial heavy-mineral content, the kind of material that waves and currents concentrate into placers and that can markedly raise local radioactivity, as seen dramatically in the monazite-rich black sands of Kerala on India’s south-west coast.

Compared with other Indian and international beaches, Jampore sits in a middle ground. Kerala’s high-background radiation area shows thorium-232 activities that can reach thousands of becquerels per kilogram, far beyond anything measured at Daman. Tamil Nadu beach sands typically report radium-226 between 13 and 198 becquerels per kilogram, while the Odisha and Andhra coasts fall in the tens to low hundreds. Globally, beaches in Ghana, Turkey and Thailand report broadly similar values, with radium isotopes in the tens and potassium-40 in the low hundreds of becquerels per kilogram. Jampore’s fine fraction is moderately elevated relative to many of these sites, but remains well below the classical high-background zones, meaning the beach is radiologically ordinary while still being dynamically informative.

The most consequential finding concerns the ratio of the two radium isotopes. Across the fine fraction the radium-226 to radium-228 ratio ranged from 0.29 to 0.55, and in the medium fraction from 0.39 to 0.61. Crucially, zones with lower ratios coincided with higher total gamma counts. Building on earlier work in the Yangtze Estuary, where smaller radium ratios were linked to sediment accretion, the researchers interpret the low-ratio, high-count areas of Jampore beach as zones where sand is accumulating. The strong linear correlation between the two radium isotopes, with a coefficient of determination of 0.9878, suggests they share a common origin and are governed by the same adsorption and desorption processes, which makes their ratio a stable and interpretable indicator.

The in-situ measurements also proved to be a surprisingly faithful proxy for laboratory analysis. Correlation plots showed that the spatial pattern of total gamma counts closely mirrors the distributions of both radium-226 and radium-228, but not potassium-40. The reason lies in nuclear structure: the uranium and thorium series emit multiple high-intensity gamma lines, including strong peaks at 609.3 and 1764.5 kiloelectronvolts for the radium-226 chain and at 583.2 and 2614.5 kiloelectronvolts for the radium-228 chain, whereas potassium-40 emits only a single gamma ray at 1460.82 kiloelectronvolts with a modest ten percent emission probability. The integrated field signal is therefore dominated by the radium chains, which is precisely what makes a rapid field survey with a portable detector a viable stand-in for detailed laboratory spectrometry when the goal is mapping sediment regimes.

The broader motivation is methodological. Since 1954, investigations of coastal sediment dynamics have relied on artificial radiotracers produced in nuclear reactors, materials that are effective but burdened by public concern and strict regulatory clearance requirements from nuclear safety authorities. Natural radionuclides embedded in the sediment offer an alternative that requires nothing to be released. Researchers in Spain, the Canary Islands, South Africa and elsewhere have already proposed radium isotopes and lead-210 as tracers of erosion and accretion, and the Indian team frames its Jampore survey as a first step toward establishing a radiometric database and a methodology for using natural isotopes as tracers along Indian coasts. The data could also serve as benchmarks against which numerical sediment transport models can be validated, increasing confidence in their predictions.

For a beach flanked by the mouths of the Daman Ganga and Kolak rivers, where fluvial supply, wave sorting and monsoon-driven erosion continuously redistribute the sand, the ability to read accretion and erosion directly from the sediment’s own radioactivity is a genuinely practical tool. Harbour dredging, dumping-site selection and coastal protection all depend on knowing where sediment goes, and a technique that replaces costly and regulated artificial tracers with a portable detector and a GPS unit could change how coastal engineers gather that knowledge. The Jampore map is a modest survey of one four-and-a-half-kilometre beach, but it demonstrates a principle with wide reach: every shoreline already carries its own radioactive diary of movement, and learning to read it may be as simple as walking the sand with a detector in hand.

Subject of Research: Spatial distribution of natural radioactivity in beach sediments as a tracer of coastal sediment dynamics

Article Title: Investigation of distribution pattern of natural radioactivity in the sediments of Jampore beach, Daman, India

Article References: Biswal, J., Goswami, S., Yadav, V. B., Sartandel, S. J., Samantray, J. S., Pulhani, V., & Sharma, V. K. (2026). Investigation of distribution pattern of natural radioactivity in the sediments of Jampore beach, Daman, India. Discover Oceans, 3(1), Article 12. https://doi.org/10.1007/s44289-026-00124-6

Image Credits: AI Generated

DOI: 10.1007/s44289-026-00124-6

Keywords: natural radioactivity, Jampore beach, Daman, sediment dynamics, gamma spectrometry, radium-226, radium-228, potassium-40, heavy minerals, coastal erosion, accretion, EDXRF
