Natural Tritium Traces the Hidden Water Sources of Temperate Forest Trees

Deep beneath the floor of a humid temperate forest, an invisible competition is underway. Every tree in the stand is drawing water from the soil, but the question of exactly where in the soil profile those roots are drinking has long frustrated ecologists. In arid and seasonal environments, the stable isotopes of hydrogen and oxygen in water vary sharply with depth, giving scientists a natural fingerprint they can match against the water inside tree trunks. In humid temperate forests, however, frequent rainfall repeatedly remixes the soil water, washing out those isotopic gradients and leaving researchers nearly blind to the depths at which trees actually take up water. A new study from northeastern Japan now suggests that an unexpected and largely overlooked tracer, the radioactive hydrogen isotope tritium, may restore that vision.

The research, published in the journal Plant and Soil by Shogo Imada and Masaru Nagai of the Institute for Environmental Sciences in Rokkasho and their colleague Hideki Kakiuchi of the institute’s Tritium Research Center, set out to test a deceptively simple idea. If natural tritium concentrations in soil water show a clear vertical pattern near the surface, then the tritium signature of water inside tree branches could reveal which soil layers the trees have been tapping. Between the summers and autumns of 2023 and 2024, the team collected soil cores and branch samples from overstory trees at study sites in northeastern Japan, working with three species that dominate humid temperate forests of the region: the deciduous oak Quercus crispula and two pines, Pinus densiflora and Pinus thunbergii.

Tritium is the radioactive heavy isotope of hydrogen, and in the environment it exists overwhelmingly in the form of tritiated water, chemically indistinguishable from ordinary H2O. It is produced naturally in the upper atmosphere by cosmic ray interactions and has also been released by atmospheric nuclear weapons testing in the mid-twentieth century and by nuclear facilities. Because tritium is part of the water molecule itself, it moves with water through soil and plants without the complications that affect other tracers. Unlike the stable isotopes deuterium and oxygen-18, tritium does not undergo significant fractionation during most biological processes, meaning its concentration in xylem water should faithfully reflect the mixture of soil water sources a tree has absorbed. That property makes it an attractive candidate for tracing water movement through the soil-plant-atmosphere continuum.

The technical challenge is that natural tritium concentrations in today’s environment are extremely low, decades after the peak of bomb testing. To measure them, the researchers extracted water from soil and branch samples using cryogenic vacuum extraction, a technique in which samples are frozen and then heated under vacuum so that the water sublimates and condenses in a cold trap. Previous work has shown that this extraction method barely alters low-level tritium concentrations in the free water of environmental samples, which was a critical prerequisite for the study. The extracted water was then subjected to electrolytic enrichment, a process that concentrates tritiated water molecules relative to ordinary water by preferentially electrolyzing the lighter isotopologues, before the enriched samples were counted with liquid scintillation techniques to determine tritium activity.

The results were striking. At both study sites, the team observed clear vertical gradients in soil water tritium concentrations within the uppermost soil layers, within the top 10 centimeters at one site and the top 20 centimeters at the other. The gradients were not random. Tritium concentrations generally increased toward the soil surface as soil moisture decreased within these depth ranges, a pattern that points to evaporative enrichment as the likely mechanism. When water evaporates from the soil surface, remaining water becomes progressively enriched in heavier water molecules, including tritiated water, much as a drying puddle becomes saltier at its edges. The researchers suggest that this evaporation-driven process shapes a tritium profile steep enough to serve as a usable depth marker even in the isotopically homogenized soils of humid temperate climates.

With a usable soil profile in hand, the team turned to the trees. Tritium concentrations measured in the xylem water of the oak and pine branches closely matched those of soil water at depths shallower than 25 centimeters. That correspondence implies that the overstory trees at these sites were drawing the bulk of their water from the near-surface soil layers during the study periods. The finding is notable because it runs counter to the common assumption that large forest trees necessarily rely on deep water sources. Other studies in temperate hardwood forests have similarly found substantial reliance on shallow soil water, and the new tritium evidence adds an independent line of support in an environment where the conventional stable isotope approach struggles.

The broader context makes the result more than a methodological curiosity. Understanding the water uptake depth of forest trees is central to predicting how forests will respond to drought, how species coexist by partitioning belowground resources, and how water moves from soil through vegetation back to the atmosphere. Transpiration by plants is a major flux in the global water cycle, and models of land-atmosphere exchange depend on assumptions about rooting depth and water source that are difficult to verify. Global syntheses of tree water uptake patterns have revealed enormous variation across biomes, but humid temperate forests remain underrepresented, precisely because the standard tools fail there. A tracer that works where stable isotopes do not could fill a significant gap in the map of global vegetation hydrology.

Tritium has, of course, a long history in hydrology, where its radioactive half-life of about 12.3 years made it invaluable for dating young groundwater and tracing recharge in the era of bomb-era tritium fallout. Its application to plant water sourcing has been far rarer, partly because of the analytical difficulty of measuring the very low concentrations found in today’s precipitation and soils. The Japanese team’s demonstration that electrolytic enrichment combined with cryogenic extraction can resolve meaningful gradients in soil water and match them to xylem signatures suggests that the technique could be adopted more widely, particularly in regions with monitoring infrastructure for environmental tritium. The authors note that distinct vertical gradients in natural tritium can occur in near-surface soil water in humid temperate forests and may provide useful information for inferring tree water uptake depths, a conclusion that opens the door to comparative studies across sites and seasons.

Cautions remain. The study covered two growing seasons at sites in northeastern Japan, and the observed gradients depended on evaporative enrichment, which may weaken under prolonged wet weather or differ across soil textures. The researchers also note that interactions between tritiated water and soil minerals, such as adsorption and exchange in clay-rich horizons, could complicate profiles in some settings, although such effects appear limited in the near-surface layers examined here. Seasonal variation in precipitation tritium inputs adds another layer of variability that future work will need to quantify. Still, the study demonstrates that a tracer once valued mainly for tracking fallout and groundwater age can be repurposed to answer one of ecology’s most persistent hidden questions: how deep the roots of a forest actually reach. As climate change intensifies drought stress in even the wettest temperate forests, knowing where trees drink may prove essential to forecasting which forests endure and which fade.

Subject of Research: Use of natural tritium as a tracer to estimate the water uptake depth of trees in humid temperate forests

Article Title: Effectiveness of the use of natural tritium as a tracer to estimate the water uptake depth of humid temperate trees

Article References: Imada, S., Nagai, M., & Kakiuchi, H. (2026). Effectiveness of the use of natural tritium as a tracer to estimate the water uptake depth of humid temperate trees. Plant and Soil. https://doi.org/10.1007/s11104-026-09089-z

Image Credits: AI Generated

DOI: 10.1007/s11104-026-09089-z

Keywords: tritium, water uptake depth, humid temperate forest, soil water isotopes, xylem water, cryogenic vacuum extraction, electrolytic enrichment, evaporative enrichment, root water uptake, forest ecology, Japan, Plant and Soil
