1. Design and Fabrication
1.1 TFLN Modulator
- Substrate: 360 nm X-cut single-crystalline LiNbO3 (LN) thin film on 2.5 µm SiO2 on quartz (NanoLN).
- Patterning: Waveguides and multi-mode interference (MMI) structures via electron-beam lithography (EBL) and reactive ion etching (fluorine-based).
- Waveguide Specs:
- Sidewall angle: 72°
- Slab thickness: 180 nm
- Rib height: 180 nm
- Edge Couplers: Developed by additional slab etching.
- Cladding: 1.2-µm PECVD SiO2.
- Electrodes:
- 180-nm NiCr layer for resistor/terminator.
- 1-µm gold transmission lines and DC electrodes via lift-off.
- Post-Processing: Device end face diced, lapped, polished for enhanced coupling.
- Process: Compatible with foundry standard lithography/etching ensuring reproducibility and scalability.
1.2 Modified UTC-PD
- Epitaxial layers:
- 180-nm InGaAs absorber with 80-nm undepleted graded doping region for quasi-electric field promoting transport.
- 100-nm depleted region creating high field at InGaAs/InP heterojunction.
- 220-nm lightly n-doped InP drift layer for carrier transit.
- 30-nm heavily doped InP cliff layer to sustain high electric field, enabling velocity overshoot and minimizing carrier pile-up.
- Enhancements:
- 4-µm benzocyclobutene dielectric layer beneath coplanar waveguides for low parasitic capacitance and robustness.
- Extended InP drift layer doubles as upper cladding for InGaAsP waveguide.
- 400-nm InGaAsP waveguide engineered for efficient evanescent coupling.
- Fabrication:
- Metal–organic chemical vapor deposition of epilayers on 2-inch InP.
- Ti/Pt/Au p-type contacts, Ge/Au/Ni/Au n-type contacts with thermal annealing.
- Triple-mesa defined by ICP dry etching and selective wet etching.
- Benzocyclobutene dielectric passivation and Ti/Au coplanar waveguides deposited.
- Process: Standard III–V semiconductor wafer-scale compatible.
2. Characterization of EO/OE Response
2.1 TFLN Modulator
- Low frequency Vπ (Vπ,LF): Measured as 5.1 V via 100 kHz triangular voltage sweep.
- Frequency-dependent calculation:
[
V{\pi, \mathrm{RF}} = V{\pi, \mathrm{LF}} \times 10^{-\frac{\mathrm{EO}S_{21}}{20}}
] - EO bandwidth measurement:
- Low-frequency (<110 GHz): Vector Network Analyzer (Keysight N5222B + N5292A + N4372E).
- High frequency (110–220 GHz): Frequency multiplier upconversion, measured by Optical Spectrum Analyzer (OSA).
- Sideband power normalization:
[
Pn = \frac{P{\text{carrier}}}{P_{\text{sideband}}}
] - Vπ,RF calculation:
[
V_{\pi,\mathrm{RF}} = \frac{\pi}{4} V_p \sqrt{P_n}
] - EO response expressed via:
[
\mathrm{EO}S{21} = -20 \log\left(\frac{\pi}{4 V{\pi, \mathrm{LF}}}\right) – 20 \log(V_p) – P_c + P_s
] - Measurement uncertainty dominated by OSA: ±0.4 dBm power translates to ±0.4 dB bandwidth uncertainty.
2.2 Modified UTC-PD
- Setup: Optical heterodyne with two tunable lasers producing beat frequencies:
[
f_{\text{beat}} = \frac{c}{\lambda_1} – \frac{c}{\lambda_2}
] - Output RF power under full modulation:
[
P_{\text{ideal}} = \frac{1}{2} RL I{\text{ph}}^2
]
where (R_L = 50 \Omega). - Frequency ranges:
- DC to 110 GHz: Power meter + 110-GHz GSG probe.
-
110 GHz: THz power meter + waveguide probes.
- **Losses calibrated/de-embedded for accuracy.
3. Data Transmission Experiments
3.1 Short-Reach IMDD
- Signal generation: Pseudorandom bit sequence by AWG (Keysight M8199B), symbol rates 112–256 Gbaud.
- Amplification: High-bandwidth electronic amplifier (SHF T850 C).
- Modulation: TFLN modulator encodes NRZ, PAM-4.
- Detection:
- DSO with 120-GHz optical sampling.
- 70-GHz RTO + 110-GHz PD for real transmission.
- DSP: No bandwidth compensation for eye diagrams; complex-biGRU for signal recovery and BER.
3.2 Wireless Coherent Optical Transparent Relaying
- Optical baseband: Silicon coherent transmitter + 1,550 nm laser.
- IQ modulation: AWG for QPSK, 16-, 32-QAM.
- LO: Tunable ECL offset by 180 GHz generating THz signals by heterodyning in UTC-PD.
- THz Tx/Rx: Horn antennas (26 dBi gain), 20 cm spacing.
- Signal amplification: 145–220 GHz LNA with 24 dB gain.
- EO conversion: TFLN modulator driven by THz RX output.
- Filtering and amplification: Tunable FBG + EDFA.
- Reception: Optical modulation analyzer with LO laser.
- Wireless extension: 4 m link uses 40 dBi lens antennas.
3.3 DSP Processing
- Baseline DSP: Gram–Schmidt normalization, matched filtering, equalization (CMA), carrier recovery, frequency offset estimation, blind phase search, and orthogonalization.
- complex-biGRU: Further equalization using a deep bidirectional GRU neural network.
4. complex-biGRU Algorithm
-
Architecture:
- Five-layer input-processing-output network.
- Input: Complex symbols separated into I and Q components.
- Complex-biGRU layer: simultaneous bidirectional processing of I and Q.
- Fully connected linear layer.
- Multi-level nonlinear activation function adapted to signal modulation format.
- Activation function: Multi-threshold saturating, enabling better classification of multi-level modulations (PAM-4, PAM-6, 16-QAM, 32-QAM):
[
f(x) = \frac{2 \alpha_2}{1 + e^{-\alpha_1 (x – 2\mu)}} – \alpha_2 + 2\mu \alpha_2
]where (\alpha_1) controls gradient, (\alpha_2) maintains continuity, and (\mu) sets level thresholds depending on modulation.
- Purpose: Mitigate nonlinear distortions causing ‘jail window’ patterns, improving BER and FEC coding performance.
