Tantalum-Loaded Gel Embolic Shows Promise for Shrinking Hypervascular Kidney Tumors

Interventional radiologists at the University of North Carolina at Chapel Hill have reported encouraging early results with a novel embolic agent designed to choke off the blood supply of hypervascular kidney tumors. In a single-center retrospective study published in CVIR Oncology, a team led by Sandra Gad and Nima Kokabi used a tantalum-loaded nanocomposite hydrogel known as Obsidio Conformable Embolic, or Ta-OCE, to treat ten patients with either renal cell carcinoma, the most common malignant kidney tumor, or angiomyolipoma, the most common benign one. The procedure, called renal artery embolization, achieved complete occlusion of the targeted vessels in every single patient, a technical success rate of one hundred percent, and every tumor that could be followed on imaging shrank measurably within weeks of treatment.

The clinical problem the technology addresses is a serious one. Hypervascular renal tumors are richly supplied with blood vessels and carry a well-known propensity for spontaneous retroperitoneal bleeding, which can become life-threatening and often demands urgent intervention. Current management options include active surveillance, renal artery embolization, thermal ablation, and surgery, with the choice depending on tumor size, vascularity, and patient-specific factors. Embolization, first described in 1973, has gained traction as a minimally invasive alternative because it can induce tumor shrinkage through ischemia while dramatically reducing hemorrhage risk. It is also frequently used before thermal ablation or surgery to cut down on intraprocedural bleeding, tumor seeding, and overall tumor burden.

What has been missing, the researchers note, is any standardized recommendation about which embolic agent to use. Clinicians have employed a bewildering variety of materials, including metallic coils, absolute ethanol, iodized oil, liquid embolics such as ethylene vinyl alcohol copolymer, N-butyl cyanoacrylate glue, and particulate agents. Each comes with its own advantages and drawbacks, and the choice often boils down to operator preference rather than evidence. Ta-OCE, developed by Boston Scientific and cleared by the FDA through the 510(k) pathway for embolization of hypervascular tumors and peripheral bleeding in vessels of three millimeters or smaller, was engineered to combine the strengths of several of these materials in a single ready-to-use formulation.

The material itself is technically intriguing. Ta-OCE is a shear-thinning hydrogel loaded with tantalum microparticles, which make it visible under fluoroscopy. When injected through a microcatheter, it conforms to the shape of the target vessel and produces mechanical occlusion rather than relying on the patient’s own clotting system, a crucial distinction for patients with coagulopathy. It is non-adhesive, so it does not glue the catheter in place the way cyanoacrylate can, and it solidifies within seconds, faster than the polymerization process required for ethylene vinyl alcohol copolymer. Because its tantalum concentration is relatively low, it generates minimal beam-hardening artifact on computed tomography, an important consideration when radiologists need to spot ongoing hemorrhage on post-procedure scans.

In the study, ten consecutive patients with a mean age of 64.1 years, 46 percent of them female, underwent selective renal artery embolization with Ta-OCE between mid-2023 and mid-2024. Five had renal cell carcinoma and five had angiomyolipoma, one of the latter associated with tuberous sclerosis. Under moderate sedation, the team advanced a 2.0 French microcatheter through a 5 French base catheter via a radial or femoral arterial approach, mapped the tumor’s feeding arteries with digital subtraction angiography, and confirmed complete targeting with three-dimensional cone-beam computed tomography before injecting the embolic until flow at the microcatheter tip stagnated. Thirteen arteries were treated in total, with a median embolic volume of just 0.25 milliliters and a median fluoroscopy time of 16 minutes.

The results were striking. Technical success, defined as complete occlusion of the target vessels on the final angiogram, was achieved in all ten patients. Among the five angiomyolipoma patients, follow-up MRI at three months showed complete devascularization of the tumors in every case. Nine of the ten patients had follow-up imaging at a mean of 56 days, and all nine tumors had shrunk, with a mean reduction in maximum diameter of 1.03 centimeters, roughly 21 percent, a change that reached statistical significance. No target vessel recanalization was observed, meaning the embolized arteries stayed closed. One patient went on to nephrectomy for definitive treatment.

Renal function, a critical concern given the kidney’s end-artery anatomy and lack of substantial intrarenal collaterals, was essentially preserved. In the eight patients for whom data were available, the mean glomerular filtration rate declined from 72.8 to 63 milliliters per minute per 1.73 square meters, a mean percentage change of minus 13.5 percent, which was not statistically significant. The authors attribute this preservation to the ability to deliver Ta-OCE superselectively into the tumor vessels while sparing the surrounding normal parenchyma. Notably, three patients in the cohort had low platelet counts, and because Ta-OCE occludes mechanically rather than through thrombosis, no rebleeding occurred in any of them.

Safety was also favorable. Only one adverse event was recorded, a case of intraoperative shortness of breath managed with supplemental oxygen and attributed to volume overload in a patient with preexisting heart failure rather than to the embolization itself. The procedure was otherwise well tolerated, with patients reporting minimal intra- and post-procedural pain compared with the discomfort often associated with agents like ethylene vinyl alcohol copolymer and particles, possibly reflecting the hydrogel’s biocompatibility. No significant bleeding requiring further intervention occurred, and no long-term sequelae were observed.

For the renal cell carcinoma patients, embolization served as a bridge to other therapies. One was treated for persistent hematuria, one received palliative embolization before nephrectomy, and three underwent embolization roughly four to eight weeks before percutaneous cryoablation, a staged approach designed to ensure complete devascularization and reduce hemorrhage risk during freezing. In one illustrative case, a 65-year-old woman whose partial nephrectomy had failed due to adhesions underwent embolization followed by cryoablation, with follow-up CT showing an approximately 18 percent reduction in lesion diameter and notably limited artifact from the embolic material. The sequential embolization-then-ablation strategy has previously been shown to reduce collecting system injury and the number of probes needed, and the ongoing multicenter EMBARC trial of neoadjuvant embolization before ablation is eagerly awaited.

The authors are careful to frame these findings appropriately. The study is small, retrospective, nonrandomized, and single-center, with no cost analysis and potential observer bias in assessing vessel recanalization, so it cannot establish Ta-OCE’s superiority over conventional agents, some of which have reported technical success rates as low as fifty percent in comparable cohorts. Still, the combination of one hundred percent technical success, durable occlusion, significant tumor shrinkage, preserved renal function, and a clean safety profile positions Ta-OCE as a genuinely promising option, particularly for emergent bleeding, coagulopathic patients, and pre-ablation devascularization. The researchers call for prospective, ideally multicenter studies to define the ideal clinical scenarios for this conformable embolic, and if larger trials confirm these early results, a ready-to-use gel that plugs tumor arteries in seconds could become a routine tool in the interventional radiology arsenal.

Subject of Research: Renal artery embolization of hypervascular renal tumors using a tantalum-loaded conformable hydrogel embolic

Article Title: Technical and Clinical Outcomes of Embolization of Hypervascular Renal Tumors Using Tantalum-Loaded Obsidio Conformable Embolic (Ta-OCE): a single-center experience

Article References: Gad, S., Mohnasky, M., Schrank, Z., Harris, B., Mody, P., Villalobos, A., Caddell, A., Dezfulian, A., & Kokabi, N. (2025). Technical and Clinical Outcomes of Embolization of Hypervascular Renal Tumors Using Tantalum-Loaded Obsidio Conformable Embolic (Ta-OCE): a single-center experience. CVIR Oncology, 1(1), Article 25. https://doi.org/10.1007/s44343-025-00025-z

Image Credits: AI Generated

DOI: 10.1007/s44343-025-00025-z

Keywords: renal artery embolization, Ta-OCE, conformable embolic, renal cell carcinoma, angiomyolipoma, interventional radiology, tantalum hydrogel, cryoablation, tumor devascularization, kidney tumors, embolic agents, minimally invasive
