Papermaking Waste Becomes a Gel That Turns Heat and Sunlight into Electricity

Every year, the global paper industry churns out millions of tonnes of a dark, syrupy by-product known as black liquor, a caustic soup left over after wood is broken down into pulp. For decades, this waste stream has been burned for its caloric value or processed into commodity chemicals, but a large fraction of its embedded chemical potential remains underexploited. Now, a team of researchers reporting in the Journal of Bioresources and Bioproducts has demonstrated a striking new route for this material: transforming lignosulfonate, a major component of papermaking black liquor, into a soft, quasi-solid gel that can convert modest temperature differences and even ordinary sunlight directly into electrical power. The work sits at the intersection of two pressing challenges, namely the recovery of low-grade waste heat and the valorization of industrial biomass residues, and it offers a single material that addresses both at once.

The scientific foundation of the new device is the thermogalvanic effect, an electrochemical phenomenon in which a temperature gradient applied across a redox-active electrolyte generates a measurable voltage. In a conventional thermogalvanic cell, two electrodes are held at different temperatures while reversible oxidation and reduction reactions proceed at different rates at each electrode. The imbalance in reaction equilibria produces a difference in electrode potential, and the resulting thermovoltage can drive a current through an external circuit. Because the effect does not require boiling fluids, turbines, or mechanical motion, it is particularly attractive for harvesting low-grade heat, the diffuse thermal energy below roughly 100 degrees Celsius that is released by industrial processes, cooling operations, electronics, and even the human body. Converting such small temperature differences into useful electricity has long been difficult, and most existing approaches either deliver too little power or rely on expensive, resource-constrained materials.

That last point is where the new study makes its most distinctive contribution. Many high-performing thermogalvanic systems depend on metal-based redox couples, such as ferroferricyanide complexes, which raise questions about cost, resource availability, and environmental sustainability at scale. The researchers instead turned to lignin, the aromatic biopolymer that gives wood its rigidity and that accumulates in enormous quantities during chemical pulping. Lignin and its sulfonated derivatives are rich in phenolic structures, which include quinone and hydroquinone moieties. These functional groups are electrochemically active and can shuttle reversibly between oxidized and reduced states, making them natural candidates for a redox electrolyte derived entirely from renewable biomass. In effect, the researchers recognized that the very molecules paper mills discard are already equipped with the chemical machinery needed for thermoelectrochemical energy conversion.

To activate this machinery, the team combined lignosulfonate with ammonium persulfate, a strong oxidizing agent. The persulfate oxidizes a portion of the lignin-derived phenolic groups, establishing a redox couple between quinone and hydroquinone species within the solution. When a temperature gradient is applied across this liquid electrolyte, the temperature-dependent equilibria of these reversible reactions generate a thermovoltage between the electrodes. The researchers systematically optimized the composition of the liquid system and reported a Seebeck coefficient of 2.92 millivolts per kelvin, a figure that quantifies how much voltage the electrolyte produces per unit of temperature difference. For a waste-derived material, this performance is notable, and it established a promising baseline before the team moved to the more challenging task of immobilizing the electrolyte in a solid-like form.

Liquid electrolytes, however mobile and conductive, are awkward for practical devices. They can leak, evaporate, and require careful containment, which complicates the design of wearable, flexible, or integrated power units. The researchers therefore embedded their lignosulfonate-based electrolyte into a poly(vinyl alcohol) matrix using freeze-thaw gelation, a simple physical crosslinking process in which repeated freezing and thawing cycles induce the polymer chains to organize into a stable hydrogel network. The resulting quasi-solid material, designated LSAK/PVA, retains the redox-active lignin chemistry while gaining the mechanical robustness and form factor of a gel. This strategy follows a broader trend in energy materials research, in which functional liquids are gelled to combine electrochemical performance with the handling advantages of solids, but it is unusual in sourcing the entire redox system from an industrial waste stream.

The gel did not merely preserve the performance of the liquid; it improved on it. At an optimized lignosulfonate concentration, the LSAK/PVA thermogalvanic gel achieved a Seebeck coefficient of 4.3 millivolts per kelvin, substantially higher than the liquid precursor, along with a maximum output power density of 976 microwatts per square meter per square kelvin. To demonstrate that individual gel elements could be scaled into something practically useful, the researchers connected eleven units in series. Under a temperature difference of 40 kelvin, the series-connected device generated approximately 1.56 volts and delivered 1.75 microwatts of power, enough to operate small electronic devices such as a timer and a calculator. While these power levels are modest in absolute terms, they are meaningful for the growing ecosystem of low-power electronics, sensors, and Internet-of-Things nodes that require only microwatts to function and that could otherwise depend on batteries with limited lifetimes.

Perhaps the most conceptually elegant demonstration in the study involves the waste stream itself. Rather than treating black liquor merely as a source of lignosulfonate feedstock, the researchers showed that the material could directly harvest the heat released as hot black liquor cools. When heated black liquor was allowed to cool, the gel system generated an open-circuit voltage of about 45 millivolts during the cooling process. This result illustrates a circular scenario in which a single industrial by-product serves simultaneously as the active redox material of the energy converter and as the thermal source that drives it. Pulp mills handle black liquor at high temperatures as a matter of routine, and capturing even a portion of the thermal energy released during its processing, using a device built from the liquor’s own constituents, would add a new layer of value to an operation that already recovers significant energy by combustion.

The gel’s abilities extend beyond waste heat into solar energy harvesting, which broadens its potential deployment considerably. Under simulated sunlight with an irradiation intensity of 1 kilowatt per square meter, comparable to standard terrestrial solar conditions, the gel developed an internal temperature difference of approximately 25 kelvin and generated an open-circuit voltage of about 0.1 volt. The photothermal conversion relies on the gel’s ability to absorb sunlight and establish a thermal gradient across its thickness, which the thermogalvanic chemistry then translates into electricity. Stability is a critical concern for any device intended for continuous outdoor operation, and the researchers addressed this with a five-cycle test that showed stable voltage output across repeated illumination cycles. Encouragingly, the performance carried over from the laboratory to the field: an outdoor device exposed to natural sunlight produced a thermovoltage of 0.33 volts after 30 minutes of light exposure, indicating that the material can function under real, variable environmental conditions rather than only under carefully controlled lamps.

Taken together, the results sketch a material strategy with implications that reach well beyond the paper industry. The authors suggest that lignin-based thermogalvanic materials could provide a pathway for recovering otherwise underused low-grade thermal energy while simultaneously adding value to industrial biomass waste. In this framing, lignin is no longer merely a low-cost fuel or a feedstock for commodity chemicals but an active functional component in energy conversion devices. The approach aligns with the principles of waste valorization, in which residues are upgraded into products of higher economic and functional value, and it does so using abundant, metal-free chemistry that avoids the supply-chain and environmental concerns associated with many inorganic thermoelectric materials. If the performance of such gels can be further improved and their manufacture integrated into existing pulp mill operations, the dark by-product of papermaking could find a second life as a soft, sustainable material that quietly harvests the heat and sunlight that would otherwise simply dissipate.

Subject of Research: Lignin-based thermogalvanic gels from papermaking waste for heat and solar energy conversion

Article Title: Papermaking waste turned into a gel for harvesting heat and sunlight

Article References: Papermaking waste turned into a gel for harvesting heat and sunlight. (n.d.). Original publication

Image Credits: AI Generated

DOI: Not provided

Keywords: thermogalvanic gel, lignin, lignosulfonate, black liquor, waste heat recovery, solar energy, thermogalvanic effect, biomass valorization, poly(vinyl alcohol), Seebeck coefficient, papermaking waste, redox electrolyte
