In the relentless pursuit of energy-efficient and environmentally benign light-emitting technologies, researchers have turned their attention toward novel hybrid materials that can revolutionize solid-state lighting. In a compelling advance, a team of scientists has unveiled a non-toxic copper–iodide-based hybrid that exhibits near-perfect photoluminescence quantum yield paired with stable, deep-blue emission. This breakthrough not only promises a leap forward in the performance of deep-blue light-emitting diodes (LEDs) but also marks a critical step toward sustainable, scalable lighting solutions.
The significance of deep-blue emission in lighting and display applications cannot be overstated. Blue light forms the cornerstone of full-color displays and efficient white light generation when combined with red and green emissions. However, achieving efficient, stable, and environmentally friendly deep-blue emitters has posed persistent challenges. Traditional materials often suffer from toxicity, poor stability, or inefficient charge transport. The copper–iodide hybrids introduced here circumvent these obstacles through their unique crystal and electronic structures, enabling highly tunable optical properties with exceptional photoluminescence efficiencies.
At the heart of this development lies a meticulously engineered copper–iodide hybrid material delivering an astonishing photoluminescence quantum yield (PLQY) of 99.6%, virtually reaching unity. Emitting at a precise wavelength of 449 nanometers with color coordinates at (0.147, 0.087), the material sets a new benchmark for deep-blue luminophores. Such a near-unity PLQY indicates that almost all absorbed photons are re-emitted, signifying minimal non-radiative losses—an essential criterion for high-performance LEDs.
The fabrication strategy employed exploits the solution-processability of the copper–iodide hybrid, enabling cost-effective and scalable thin-film deposition techniques. By utilizing the hybrid as the sole active emissive layer, the team constructs LEDs that efficiently convert electrical energy into blue light. Yet, it is the dual interfacial hydrogen-bond passivation approach that underpins the remarkable device performance. This elegant method involves the sequential application of a hydrogen-bond-acceptor self-assembled monolayer followed by an ultrathin polymethyl methacrylate (PMMA) capping layer, together refining the interfaces at both sides of the emissive layer.
Such interfacial engineering serves multiple critical functions. Hydrogen bonds formed at these interfaces effectively mitigate trap states and lipidic defects that typically quench luminescence or hinder charge injection. The PMMA capping layer further stabilizes the emissive film and prevents undesirable environmental interactions, thereby enhancing operational stability. This synergetic approach markedly optimizes charge carrier balance, which is crucial for maximizing external quantum efficiency and device longevity.
Resultantly, the developed LEDs achieve a peak external quantum efficiency (EQE) of 12.57%, a luminance reaching nearly 4,000 cd/m², and maintain deep-blue emission with color coordinates very close to the native material’s photoluminescence. These metrics place the devices among the highest-performing non-toxic deep-blue LEDs reported to date. Moreover, the operational half-lifetime of 204 hours under ambient conditions demonstrates the robustness of these devices, marking a significant advance toward practical applications.
The core scientific insight underpinning this performance advances understanding of the emission mechanism and charge transport physics intrinsic to copper–iodide hybrids. The material’s inorganic-organic hybrid structure enables strong spin–orbit coupling and effectively confines excitons, thereby promoting radiative recombination pathways. Concurrently, the charge transport characteristics sustain balanced injection of holes and electrons, reducing the likelihood of exciton quenching processes that degrade efficiency.
Beyond the fundamental advances, the researchers successfully demonstrate the scalability of their approach by fabricating a large-area device spanning four square centimeters that sustains comparable efficiency metrics. This scalability underscores the industrial relevance of the technology and its potential integration into commercial solid-state lighting and high-definition display platforms. Such scalability could pave the way for future eco-friendly, bright, and reliable deep-blue sources.
Copper–iodide hybrids represent a new class of emissive materials that hold a promising blend of tunability, sustainability, and process compatibility. Their relative abundance and non-toxic nature position them as attractive alternatives to current blue-emitting materials, often based on rare or hazardous elements. The realization of efficient deep-blue emission with high photostability in these hybrids signals a paradigm shift in optoelectronics, especially in applications demanding stringent color purity and operational durability.
Furthermore, the dual hydrogen-bond passivation technique introduced here offers a versatile template for surface and interface modification strategies across a spectrum of optoelectronic devices. By specifically targeting the heterojunctions flanking the emissive layer, the method addresses critical non-radiative recombination centers and energy barriers that impede efficient device operation. This insight carries broad implications beyond copper–iodide systems, potentially benefiting perovskite LEDs, organic LEDs, and other hybrid semiconductor platforms.
The implications of these findings extend even further into sustainable technology development. By harnessing non-toxic materials and solution-processing methods, manufactures could reduce reliance on scarce and environmentally damaging elements while benefitting from low-cost fabrication. As the world shifts toward cleaner technologies, innovations such as these hybrid copper–iodide LEDs pave the pathway for greener lighting solutions that do not compromise on performance or color quality.
Ultimately, the work constitutes a significant milestone in the pursuit of high-performance deep-blue emitters. It bridges the vital gap between fundamental photophysical properties and practical device engineering, yielding a device that excels in efficiency, luminance, stability, and environmental friendliness. Such advances not only enrich the scientific landscape but also answer burgeoning market demands for versatile and sustainable lighting and display technologies.
Looking ahead, the exploration of further composition tuning, novel passivation schemes, and hybrid architectural innovation could unlock even greater efficiencies and lifespans. Integration of these materials within flexible, transparent, or patterned substrates may open fresh opportunities in wearable devices, augmented reality displays, and beyond. The versatility embodied by copper–iodide hybrids marks just the beginning of a promising era for deep-blue light emitters and solid-state optoelectronics overall.
By combining meticulous chemical design, sophisticated interface engineering, and a clear eye toward scalability, this work exemplifies how targeted material innovation can dramatically improve LED technologies. The demonstration of near-unity photoluminescence yield coupled with robust device performance reiterates the immense potential of solution-processed copper–iodide hybrids as future foundations for eco-conscious, high-efficiency lighting applications worldwide.
Subject of Research: Deep-blue light-emitting diodes based on non-toxic copper–iodide hybrid materials with enhanced performance via dual interfacial hydrogen-bond passivation.
Article Title: Dual interfacial H-bonding-enhanced deep-blue hybrid copper–iodide LEDs.
Article References:
Zhu, K., Reid, O., Rangan, S. et al. Dual interfacial H-bonding-enhanced deep-blue hybrid copper–iodide LEDs.
Nature (2025). https://doi.org/10.1038/s41586-025-09257-8
