Cervical spinal cord stimulation linked to stronger arm muscle activation after chronic stroke

A small pilot study from Taiwan reports that electrical stimulation delivered to the cervical spinal cord was associated with stronger voluntary muscle activation in the weakened arms of people living with chronic stroke hemiparesis. The prospective feasibility study, conducted at Hualien Tzu Chi Hospital and published in Frontiers in Behavioral Neuroscience, followed four adults whose strokes had occurred between 6 and 28 months earlier and whose upper-limb function ranged from severe to moderate impairment on the Fugl-Meyer Assessment for Upper Extremity, with baseline scores between 6 and 35.

Upper-limb hemiparesis is one of the most stubborn consequences of stroke. By the chronic phase, conventional rehabilitation often yields limited further gains, leaving many survivors unable to use the affected arm in daily life. The researchers tested cervical epidural electrical stimulation as a way to amplify the residual corticospinal drive that survives after cortical injury, by modulating the excitability of spinal interneurons through contact-specific stimulation along the spinal cord.

Each participant underwent implantation of bilateral cervical paddle leads spanning the C3 to T1 segments. During surgery, the team performed contact-specific motor mapping using bipolar stimulation at 2 Hz, producing individualized maps of which spinal contacts recruited which muscles. These maps then informed the selection of stimulation parameters for each person, an approach the authors describe as precision neurorehabilitation.

The intraoperative mapping revealed a level-dependent proximal-to-distal recruitment gradient consistent with the known somatotopic organization of the cervical cord, with more rostral contacts tending to activate proximal muscles and more caudal contacts activating distal ones. Notably, this orderly organization appeared preserved despite chronic cortical injury, suggesting that the spinal circuitry retained a usable topographic structure even years after stroke.

To measure the acute effect of stimulation, the researchers recorded task-related surface electromyography while participants performed six standardized upper-limb movements, first with stimulation on and then with it off. The ratio of EMG amplitude between the two conditions served as an index of stimulation efficacy. Under stimulation, EMG amplitude during voluntary movement increased across most muscles and tasks, with facilitation ratios reaching as high as 18.0 in the wrist flexors during precision grasping.

The clinical results after four weeks of EES-augmented rehabilitation were cautiously encouraging. All four participants improved on the Fugl-Meyer Upper Extremity scale, with gains ranging from 4 to 8 points. One participant exceeded the minimal clinically important difference threshold of 5 to 6 points, and a second approached it. Action Research Arm Test scores improved in three of the four participants, reflecting gains in real-world arm and hand tasks.

Spasticity told a more nuanced story. Muscle tone remained stable in three participants on the Modified Ashworth Scale, but one exhibited an isolated increase in elbow flexor tone, which the authors interpret as consistent with stimulation-mediated amplification of hyperreflexic flexor circuits. This observation underscores that amplifying residual spinal drive can, in principle, strengthen pathological reflex patterns as well as voluntary movement, and it highlights the need for careful parameter tuning in future applications.

The authors emphasize that these are preliminary findings from an uncontrolled pilot with only four participants, so the improvements cannot be attributed to stimulation alone; the concurrent rehabilitation and natural recovery dynamics in the chronic phase also warrant consideration in future designs. Registered on ClinicalTrials.gov as NCT05981989, the study was designed to establish feasibility, characterize individual cervical motor recruitment patterns, and generate the neurophysiological rationale needed for properly controlled trials. Within those limits, the results suggest that contact-specific cervical epidural stimulation, guided by individualized motor mapping, may represent a feasible adjunct intervention for upper-limb rehabilitation after chronic stroke.

Subject of Research: Cervical epidural spinal cord stimulation and voluntary upper-limb muscle activation in chronic post-stroke hemiparesis

Article Title: Cervical epidural spinal cord stimulation is associated with enhanced voluntary upper-limb muscle activation in chronic post-stroke hemiparesis: a pilot feasibility study

Article References: Wu, C.-C., Huang, H.-L., Chen, Y.-C., Wang, P.-K., Wu, M.-Y., Yan, L.-C., Lin, S.-Z., & Tsai, S.-T. (2026). Cervical epidural spinal cord stimulation is associated with enhanced voluntary upper-limb muscle activation in chronic post-stroke hemiparesis: a pilot feasibility study. Frontiers in Behavioral Neuroscience, 20, Article 1914244. https://doi.org/10.3389/fnbeh.2026.1914244

Image Credits: AI Generated

DOI: 10.3389/fnbeh.2026.1914244

Keywords: spinal cord stimulation, stroke rehabilitation, neuromodulation, upper-limb hemiparesis, corticospinal tract, pilot study, cervical epidural stimulation, electromyography, Fugl-Meyer Assessment, spasticity, Cervical, epidural
