In a groundbreaking development set to revolutionize the field of photodetection and imaging, researchers have unveiled a monolithically integrated near-infrared (NIR) imager constructed from crystallization- and oxidation-modulated tin-lead perovskites. This innovative device holds tremendous potential to overcome longstanding challenges in infrared imaging technology, marrying high sensitivity with cost-effective fabrication methods. The study, published in Light: Science & Applications, represents a significant leap forward in optoelectronic devices, promising applications that span from advanced biomedical imaging to enhanced night vision and telecommunications.
Near-infrared imaging has become a cornerstone in numerous scientific and industrial domains due to its ability to probe beneath the surface of biological tissues and capture images in low-light conditions. However, the fabrication of high-performance NIR imagers remains a complex and expensive endeavor, often relying on exotic materials like mercury cadmium telluride or indium gallium arsenide. These semiconductors demand intricate processing techniques and are notoriously difficult to integrate with standard silicon electronics. The team led by Yang, Liu, and Bao offers a remarkable solution by engineering a novel perovskite material system that sidesteps many of these limitations.
At the core of this breakthrough is the strategic modulation of both crystallization and oxidation processes during the synthesis of tin-lead halide perovskites. Perovskites have garnered significant attention in recent years for their remarkable optoelectronic properties and relatively facile fabrication. However, their application in NIR devices has been constrained by instability issues and the challenge of achieving efficient charge transport while suppressing defect formation. By precisely controlling crystallization dynamics, the researchers enhanced film uniformity and crystal quality, which directly improved charge carrier mobility and reduced trap states.
Simultaneously, the oxidation state of tin—a notoriously unstable component prone to oxidation from Sn(II) to Sn(IV)—was carefully modulated to maintain optimal electronic properties over extended periods. This delicate balance curtails the formation of deep-level traps that typically degrade device performance. The integration of these compositional strategies culminated in perovskite films exhibiting exceptional optoelectronic properties, with tailored bandgap energies suitable for near-infrared light absorption.
Crucially, the team succeeded in monolithically integrating these engineered perovskite materials onto complementary metal-oxide-semiconductor (CMOS) substrates, a feat that ensures seamless compatibility with existing semiconductor manufacturing infrastructure. This integration not only simplifies device fabrication but also paves the way for scalable production of cost-effective NIR imagers. The resulting devices display impressive photoresponsivity across a broad NIR spectrum, enabling high-resolution imaging with enhanced signal-to-noise ratios.
Detailed characterization confirmed that these perovskite-based imagers achieve record-breaking detectivity values rivaling those of commercial infrared detectors. The devices demonstrated rapid response times and exhibited stable performance under continuous illumination and ambient conditions, addressing a crucial hurdle in the commercialization of perovskite photodetectors. Moreover, the uniformity of the perovskite film over large areas ensures pixel-to-pixel consistency critical for high-quality imaging sensors.
Beyond the device-level achievements, the study delved into the underlying physics governing the improved performance. Advanced spectroscopic analyses illuminated the interplay between crystallization kinetics and oxidation modulation, revealing mechanisms by which defect density is minimized and carrier lifetimes are extended. This mechanistic insight provides a valuable blueprint for the future design of perovskite materials tailored for optoelectronic applications beyond imaging, including photodetectors, solar cells, and light-emitting devices.
The implications of this research extend well beyond the laboratory. The emergence of monolithic perovskite NIR imagers could transform medical diagnostics by enabling compact, highly sensitive devices for real-time tissue analysis and non-invasive monitoring. Similarly, the technology could significantly advance autonomous vehicle systems by providing cost-effective night vision capabilities that enhance safety and navigation. Telecommunications could also benefit from improved near-infrared detectors facilitating high-speed optical communication networks.
Furthermore, the authors underscore the environmental and economic advantages of utilizing tin-lead perovskites as opposed to fully lead-based compounds. By reducing lead content while maintaining robust performance, their approach aligns with growing demands for sustainable and environmentally responsible materials in electronics. The modulation techniques developed herein could serve as a template for minimizing toxic elements in perovskite-based technologies without sacrificing functional performance.
The research also highlights the scalability of the manufacturing process, noting that the solution-processing techniques employed are compatible with roll-to-roll fabrication and other high-throughput methods. This scalability is a crucial factor for transitioning from proof-of-concept devices to commercial applications, potentially lowering the entry barrier for widespread adoption of perovskite NIR imagers.
Challenges remain, particularly in fully eradicating long-term stability concerns under harsh operational environments. However, the promising lifetime metrics reported in this study, coupled with ongoing material innovation, suggest that perovskite-based infrared imagers may soon rival or surpass conventional technologies not only in performance but also in cost-effectiveness and integrability.
The fusion of material science ingenuity with device engineering presented in this work lays a robust foundation for the next generation of high-performance NIR imaging systems. As researchers continue to refine the crystallization and oxidation controls at the nanoscale, we can anticipate even further enhancements in device efficiency and durability.
In conclusion, this pioneering study spearheaded by Yang and colleagues marks a paradigm shift in near-infrared imaging technology. By harnessing the versatile properties of crystallization- and oxidation-modulated tin-lead perovskites, they have demonstrated a sustainable, scalable, and monolithically integrated platform for sensitive NIR detection. This advancement holds the promise of ushering in a new era of photonic devices with broad-reaching implications for science, industry, and everyday life.
Article References:
Yang, Z., Liu, J., Bao, H. et al. A monolithically integrated near-infrared imager with crystallization- and oxidation-modulated tin-lead perovskites. Light Sci Appl 14, 304 (2025). https://doi.org/10.1038/s41377-025-01987-8
