In a groundbreaking retrospective multicenter study published in BMC Cancer, researchers have unveiled compelling evidence supporting the use of image-guided hypofractionated radiotherapy (IGRT) as a safe and effective treatment for hepatocellular carcinoma (HCC) complicated by portal vein tumor thrombosis (PVTT). This malignancy presents significant clinical challenges, as PVTT is notoriously associated with poor prognosis and limited therapeutic options. The study meticulously evaluated the outcomes of a novel 10-fraction radiation regimen aimed at maximizing tumor control while minimizing collateral tissue damage, heralding a potential shift in managing this formidable disease.
Hepatocellular carcinoma ranks among the most lethal cancers globally, with portal vein tumor thrombosis emerging as one of its most aggressive manifestations. PVTT exacerbates the disease course by impeding hepatic blood flow and facilitating tumor dissemination, substantially diminishing survival rates. Historically, treatment for HCC with PVTT has been controversial due to the delicate balance between therapeutic efficacy and hepatic tolerance to radiation. Conventional radiotherapy approaches have struggled to deliver ablative doses without incurring unacceptable toxicity, thus spurring innovation in radiation delivery techniques.
The present study capitalized on advancements in image-guided radiotherapy, enabling precise targeting of the tumorous thrombus within the portal vein system. By exploiting hypofractionation—a technique that administers a higher dose per session over fewer treatments—the researchers sought to enhance the biological effectiveness of radiation while reducing the overall treatment duration. Specifically, patients underwent a standardized protocol consisting of 10 fractions of focused radiation, delivering a biologically effective dose (BED) ranging between 56 and 75 Gy_10, carefully calibrated to ablate malignant tissue while sparing healthy liver parenchyma.
Participants were drawn from two leading medical centers, encompassing a cohort of 69 patients treated between 2016 and early 2022 out of an initial 95. The distribution of PVTT severity was classified according to the widely accepted Liver Cancer Study Group of Japan system, encompassing four stages based on anatomical involvement of the portal vein branches, from segmental branches (Vp1) through to the main portal vein (Vp4). This stratification allowed for a granular analysis of treatment efficacy relative to the thrombus extent, a crucial variable in prognostication.
Treatment planning incorporated meticulous imaging assessments, achieving an average planning target volume (PTV) of approximately 105 cubic centimeters. Most patients (75.4%) received the full 50 Gy dose, delivered in 10 sessions. The precision offered by image guidance was instrumental in maintaining strict adherence to dose constraints, thereby minimizing radiation exposure to adjacent organs at risk. This technical rigor underpins the observed safety profile of the regimen, which is particularly noteworthy given the inherent fragility of hepatic tissue in HCC patients.
Outcomes were robust and encouraging. With a median follow-up period exceeding 10 months, the study reported a median overall survival (OS) of just over 20 months, a notable improvement compared to historical controls. The freedom from local progression (FFLP) at one year was nearly 89%, underscoring the regimen’s capacity to exert durable local tumor control within the portal venous system. Progression-free survival (PFS) was more modest at approximately 27%, reflecting the aggressive nature of the underlying disease and the challenges posed by intrahepatic and extrahepatic spread.
Tumor response evaluation employed the Response Evaluation Criteria in Solid Tumors (RECIST) version 1.1, revealing promising rates of radiological tumor regression three months post-treatment. Complete and partial responses were observed in 13% and 36.2% of cases, respectively, while nearly half of patients maintained stable disease, highlighting the potential of this RT approach to stabilize or shrink PVTT lesions substantially. Notably, only a small fraction (4.4%) experienced disease progression at the initial follow-up, indicating a high degree of early therapeutic efficacy.
Multivariate analysis elucidated prognostic factors influencing overall survival outcomes. Elevated alpha-fetoprotein (AFP) levels exceeding 600 IU/ml emerged as a significant risk factor, doubling the hazard ratio for mortality. Similarly, compromised liver function categorized as Child-Pugh Class B or C and advanced cancer staging (IVA or IVB) independently predicted worse survival. These findings reinforce the critical importance of baseline patient selection and liver reserve assessment when considering hypofractionated IGRT in advanced HCC-PVTT cases.
The safety profile was particularly reassuring, with only two patients (2.9%) experiencing severe (grade ≥3) toxicities during follow-up—one case of grade 3 hepatic enzyme elevation and one episode of acute cholangitis. The low incidence of significant adverse events underscores the advantage of image-guided delivery modalities that permit dose escalation directly to the tumor thrombus while mitigating radiation-induced liver injury and biliary complications. Such tolerability is pivotal for patients with compromised hepatic function, broadening therapeutic applicability.
This study’s findings advocate for hypofractionated IGRT as a viable and effective treatment strategy for managing PVTT in HCC patients, marking a significant advancement in the radiotherapeutic armamentarium. The regimen’s ability to achieve meaningful tumor control and survival benefit, coupled with acceptable toxicity, challenges previous paradigms that limited radiation therapy use in this population. It paves the way for integrating such approaches into multidisciplinary care pathways, potentially in combination with systemic therapies.
Technological innovations in radiation oncology, including sophisticated imaging techniques and treatment planning software, have been instrumental in realizing the promise of hypofractionated regimens. Image-guided delivery ensures that high radiation doses are tightly conformed to complex anatomical targets—crucial in liver cancer where healthy tissue preservation is paramount. These modalities offer dynamic real-time adjustments that enhance treatment accuracy, reducing inter- and intra-fraction variability that could otherwise compromise efficacy or safety.
Biological effective dose concepts underpin the rationale for hypofractionation by maximizing tumoricidal effects within a limited number of fractions. Delivering higher doses per fraction exploits the radiobiological vulnerabilities of cancer cells, inducing irreparable DNA damage and triggering apoptotic pathways more effectively than conventional fractionation schemes. This approach also offers logistical advantages by shortening treatment duration, which can improve patient convenience and resource utilization within oncology departments.
The clinical implications of these findings are considerable. Given the dismal prognosis associated with PVTT, any intervention that prolongs survival with manageable toxicity represents a major therapeutic milestone. This study’s data suggest that even patients with extensive portal vein involvement (Vp3 and Vp4) can derive substantial benefit from this radiotherapy protocol. Coupled with the identified prognostic markers, clinicians can better individualize treatment decisions and counseling regarding expected outcomes.
Future directions include prospective trials to validate these retrospective observations and to explore combinatorial strategies pairing hypofractionated IGRT with emerging systemic agents such as immune checkpoint inhibitors or targeted therapies. Molecular profiling of tumor biology may further refine patient selection, enabling personalized radiation dosing schemes optimized by genomic signatures predictive of radiosensitivity or resistance.
In summary, the integration of image-guided hypofractionated radiotherapy into the therapeutic landscape for hepatocellular carcinoma with portal vein tumor thrombosis heralds a new frontier in oncologic intervention. By harnessing precision technology and radiobiological principles, this treatment modality achieves a critical balance between efficacy and safety, offering renewed hope to patients facing one of liver cancer’s most daunting complications. As clinical experience accrues, it is poised to become a cornerstone of multidisciplinary HCC management.
Subject of Research:
Treatment efficacy and safety of image-guided hypofractionated radiotherapy for hepatocellular carcinoma complicated by portal vein tumor thrombosis.
Article Title:
Efficacy and safety of image-guided hypofractionated radiotherapy for hepatocellular carcinoma with portal vein tumor thrombosis: a retrospective, multicenter study.
Article References:
Lee, S.M., Choi, J.H., Yoon, JH. et al. Efficacy and safety of image-guided hypofractionated radiotherapy for hepatocellular carcinoma with portal vein tumor thrombosis: a retrospective, multicenter study. BMC Cancer 25, 736 (2025). https://doi.org/10.1186/s12885-025-13739-3
